Overview:
SSCTM adaptive high pressure preparative chromatography column with excellent performance
SSCTM series of adaptive high pressure preparative chromatography column and column loader has won the recognition of the majority of users with its unique innovative design and ultra-high cost performance. It is a high-throughput drug, the best choice for natural products research and development and production, ASATM adaptive preparative HPLC chromatographic column is widely applied to small molecule drugs, antibiotics, sugar substance, nucleic acid and the preparation of polypeptide and protein separation, in addition SSCTM adaptive preparative HPLC chromatographic column unique water bath jacket design is very suitable for chiral compounds break up.
Product feature introduction section
Technical parameters
Common column tube set
The material |
All post bed contact surfaces | 316LStainless steel, PTFE |
Column tube and inner wall of column tube | 316L Stainless steel (Mirror finish, Ra < 0.3μm) |
The flange | 316L Stainless steel (Mirror finish, Ra < 0.3μm) |
The piston | 316L Stainless steel (Mirror finish, Ra < 0.3μm) |
Height adjusting block | 6061 Aluminium (hard anodized surface) |
Thread screw | 6061 Aluminium (hard anodized surface) |
Spring tube | 316L Stainless steel |
Leaf spring | 304 stainless steel or spring steel (coated with anodized oxide) |
Pipelines and various joints | 316L stainless steel (joint and adapter are imported Valco® products) |
Bolt and nut | Carbon steel, American grade 8 strength |
Sieve plate | Pure titanium |
Sealing and heat shrinkable film | PTFE |
Working parameters | The length of the column hardware is 400mm | The length of 700mm column hardware |
Maximum loading column bed height | 200mm | 350mm |
Maximum working pressure | 138bar / 2000psig |
Maximum operating temperature | Loading: 15° C-30 °C, liquid phase operation: 4° C-60 °C |
Quality system certification | CE certification, ISO 9001 quality system certification |
Safety system certification | Eu PED (Pressure Directive Certification) |
Suitable for use in supercritical fluid chromatography column tube set
The material |
All post bed contact surfaces | 316LStainless steel, PTFE |
Column tube and inner wall of column tube | 316L Stainless steel (Mirror finish, Ra < 0.3μm) |
The flange | 316L Stainless steel (Mirror finish, Ra < 0.3μm) |
The piston | 316L Stainless steel (Mirror finish, Ra < 0.3μm) |
Height adjusting block | 6061 Aluminium (hard anodized surface) |
Thread screw | 6061 Aluminium (hard anodized surface) |
Spring tube | 316L Stainless steel |
Leaf spring | 304 Stainless steel or spring steel (coated with anodized oxide) |
Pipelines and various joints | 316L Stainless steel (joint and adapter are imported Valco® products) |
Bolt and nut | Carbon steel, American grade 8 strength |
Sieve plate | Pure titanium |
Sealing and heat shrinkable film | PTFE or fiberglass rubber |
The copper ring | Imports of bronze |
Working parameters | The length of the column hardware is 400mm | The length of 700mm column hardware |
Maximum loading column bed height | 200mm | 350mm |
Maximum working pressure | 276 bar / 4000psig |
Maximum operating temperature | Loading: 15° C-30 °C, liquid phase operation: 4° C-135 ˚C |
Quality system certification | CE certification, ISO 9001 quality system certification |
Safety system certification | Eu PED (Pressure Directive Certification) |
The order information
ASATM preparative chromatographic columns are available in two lengths: 40cm and 70cm, with maximum loading beds of 15cm and 35cm, respectively. The inner diameter of the column is 25mm, 30mm, 40mm, 50mm and 101mm. Water bath jacket with accurate temperature control can also be installed according to customer requirements.
The article number | Describe |
AS2017-025040 | 25mm x 40cm Common column tube set |
AS2017-025070 | 25mm x 70cm Common column tube set |
AS2017-W25070 | 25mm x 70cm SFC Suitable for column pipe set with water bath jacket |
AS2017-030040 | 30mm ID x 40cm L Common column tube set |
AS2017-040040 | 40mm ID x 40cm L Common column tube set |
AS2017-030070 | 30mm ID x 70cm L Common column tube set |
AS2017-040070 | 40mm ID x 70cm L Common column tube set |
AS2017-W30070 | 30mm x 70cm SFC Suitable for column pipe set with water bath jacket |
AS2017-W40070 | 40mm x 70cm SFC Suitable for column pipe set with water bath jacket |
AS2017-050040 | 50mm x 40cm Common column tube set |
AS2017-050070 | 50mm x 70cm Common column tube set |
AS2017-W50070 | 50mm x 70cm SFC Suitable for column pipe set with water bath jacket |
AS2017-070070 | 70mm x 70cm Common column tube set |
AS2017-W70070 | 70mm x 70cm SFC Suitable for column pipe set with water bath jacket |
AS2017-10170 | 101mm x 70cm Common column tube set |
AS2017-10170-W | 101mm x 70cm Common column tube set (with water bath jacket) |
AS2017-W10170 | 101mm x 70cm SFC Suitable for column pipe set with water bath jacket |
Best-selling accessories!
1. Protective column set
ASATMThe protective column set can effectively reduce the pollution of the filling in the SSC column, thus increasing the life of the prepared column, reducing the reinstallation frequency of the column and improving the efficiency. The protection column adopts the patented minimalist design mode and extracts the essence of SSC design, which not only realizes the function of preventing column pollution, but also eliminates the problem that other protection columns are easy to collapse and do not support reinstallation. The reinstallation process is very simple and can be completed in about 10 minutes.
The article number | Describe |
AS2017-G30 | 30mm inner diameter protective column set (suitable for 50mm inner diameter and below preparation column) |
AS2017-G50 | 50mm inner diameter protective column set (suitable for 70mm inner diameter and above preparation column) |
2. The pipe bracket
ASATMThe patented design of the pipe stand helps you easily position the pipe vertically, saving space and increasing safety requirements. The column pipe frame adopts lightweight material, and the most advanced oxidation painting process, the whole design is simple, practical and beautiful.
